TREK Monitor 15.6"

15.6" Touchscreen Monitor

With its sleek and minimalistic design, the TREK 15.6” Monitor fits wherever touchscreen functionality is required. POS, Self-Service, KDS, Price Checker, and more, TREK Monitor offers flexibility to install as either an operator touchscreen or an interactive customer facing display. Deploy countertop on the included stand or leverage the 75mm VESA pattern for pole and wall mounting. Purpose built for commercial environments, TREK Monitor features single USB-C cable convenience and rugged IP54 protection.  And, as with all TREK products, you can easily add accessories to transform TREK Monitor for any use case.

To learn more about the entire TREK family of products, please click here.

特性

1. Simplicity
TREK Monitor simplifies connectivity via a single USB-C cable which provides touch, video signal and power. Alternatively, HDMI, USB-A and power connectors are also available to support legacy connections to POS systems, PCs and compute boxes.

2. Versatility
TREK Monitor supports all TREK micro USB accessories allowing for endless configurations to support a variety of use cases.

3. Flexibility
Whether placed on the counter via the included stand or mounted onto any 75 x 75 mm VESA pole or bracket, the TREK monitor can be positioned wherever needed to best serve the customer.

4. Durability
Retail-hardened and backed by Custom’s warranty support, TREK Monitor is built to withstand the rigors of any environment.





Markets

  • Retail
  • Hospitality
  • Grocery
  • C-Store
  • Entertainment
  • Gaming, Lottery and Betting

配件

938PW010100001   Fingerprint Reader for Trek Terminal
938PW010100002   2D scanner for Trek Terminal
938PW010100003   3 Track MSR for Trek Terminal
938PW010100004   NFC/RFID Reader for Trek Terminal
938PW010100005   LED Light Bar for Trek Terminal
938PW010100006   Camera/Microphone for Trek Terminal
938PW010100012   iButton Reader for Trek Terminal
938PW010100007   Trek series POS stand all screen sizes

技术表单

Touch Display 15.6"
Resolution 1920 x 1080
Aspect Ratio 16:9
Touch Technology True-Flat PCAP multi-touch
Touch Interface USB
Brightness LCD Panel: 300 NITS | PCAP Touch: 240 NITS
Viewing Angle Horizontal: ±89° or 178° total / Vertical: ±89° or 178° total
USB Type-C 1x USB 3.0 full-functioned (DP / PD 5 V / 2 A, 12 V / 1 A)
HDMI 1x
Micro USB 3x
DC Jack 1x 2 pin
Speaker 1x 3 W
Auto Adjust Button 1x
Power Button 1x
Stand Included
VESA Mount 75 x 75 mm
Accessory Options 2D Scanner, Camera / Microphone, Fingerprint Reader, NFC / RFID Reader, iButton, Light Bar, MSR
Ingress Protection IP54 (screen side)
Operating Temperature 0° C ~ 35° C (32° F ~ 95° F)
Storage Temperature -20° C ~ 60° C (-4° F ~ 140° F)
Humidity 20% ~ 85% RH non-condensing
W x D x H 369 mm x 37 mm x 234 mm (without stand)
369 mm x 165 mm x 271.2 mm (with stand)
Weight 1.39 kg (without stand)
2.25 kg (with stand)
What’s in the Box Monitor, Stand, 1.8 m USB-C cable, Power supply, NA power cord, EU power cord
(Note: power supply required only for HDMI + USB-A connections)

楷模

932PW010100M33

932PW010100M33

Trek 15.6" Touch Monitor,Stand
