P3L

P3L

Cost-effective thermal receipt printer delivering performance, flexibility, and reliability

The affordable P3L thermal receipt printer is the perfect solution for businesses looking for reliable performance and flexibility. Designed to support existing and new applications with its triple interface design, the P3L supports USB, serial, and ethernet connectivity. Ideal for retail and hospitality, the P3L’s 200mm/second print speed ensures quick transactions at the point-of-sale. Built for longevity, it is equipped with a long-life print head, an integrated high performance buzzer and an autocutter and it's versatile thanks to the wall mounting. Engineered utilizing Custom’s 30+ years of printing expertise, the P3L is the leader for cost-effective thermal POS printers.

Characteristics

  1. Triple Interface
    The P3L comes standard with USB, Serial, and Ethernet interfaces for maximum connectivity

  2. 200mm/s Print Speed
    With a print speed of 200mm/s, the P3L will save your business time at the checkout

  3. Cost Effective
    The easy-to-use P3L is our most cost-effective POS receipt printer and includes both USB and Serial interface cables

  4. Durable
    Leveraging Custom’s 30+ years of printing expertise, the P3L features a long-life print head and autocutter

  5. Compatible with AndroidTM and iOS®
    It supports printing both from AndroidTM and iOS®, ensuring the maximum compatibility with various operating systems





MARKETS

  • Retail
  • Hospitality

Accessories

  • 58mm paper reduction guide

This product is only available for sale in Mexico and Latin America.

Technical sheet

Printing Method Thermal printing, fixed head
Number of dots 8 dots / mm
Resolution 203dpi
Printing (mm/sec) 200mm/s
Buzzer High performance integrated
Auto-cutter Cutter life 1.5 million cuts
Partial cut
Printing Direction Normal, 90°, 180°, 270°
Printing Format Height and width from 1 to 8, bold, reverse, underlined, italic
Character set Standard font, Extended Chinese GB18030-2000
Supported Barcode 1D: UPC-A, UPC-E, EAN8, EAN13, CODE39, ITF, I25, CODABAR, CODE128, CODE11, MSI
2D: PDF417, QRCODE, DATAMATRIX
Paper width 58mm (with optional paper reduction guide)
80mm
Paper weight from 55 gr to 80 gr
Sensors Low paper
Emulation CUSTOM/POS
Interfaces USB port
RS232 serial port
Ethernet port
Cash drawer port
Drivers Windows® (32/64 bit)
Linux (32/64 bit)
Tool software PrinterTool
Power supply External 24 Vdc ± 10%
Medium consumption 2.5A (12,5% dots turned on)
Head Life 150 Km
Operating temperature 0°C + 40°C
Dimensions 145 mm (L) × 195 mm (W) × 150 mm (H)
Weight 1 Kg

Models

911MX010100733

911MX010100733

PRINTER P3L 80MM ETH USB RS232 USA

Accessories
Download Datasheet
