A4 front/rear color Scanner
Custom A4 Scanners guarantee high performance (400 mm/s) of front/back color scanning and better than average data transfer (USB 3.0 at 5 Mbit/s) to support all applications with a resolution up to 600 dpi (at 73 mm/s), along with the option of integrating with third party applications. The main reference markets are: banking, industrial, aviation, railways, public transports, gaming, logistics and retail.
GENERALS | |
Processor | High speed, high performance scanner ASIC with ARM11 CPU 375 MHz |
Sensors | Paper input and output presence, paper jam and paper holding, cover open, deskew, upper and lower CIS, ultrasonic sheet overlap detection (optional) |
Drivers | Windows® (32/64 bit) – only on request WHQL and silent installation Linux (32/64 bit) |
Windows Libraries | CuDoubleSidedScannerAPI for Win32 and .NET |
Interfaces | USB 5 Gbit/s (USB 3.1) |
Memories | RAM 512 MB DDR3 |
SCANNER | |
Scanner type | Contact Image Sensor (CIS) |
Resolution | 200 dpi, 300 dpi, 600 dpi |
Light source | Colors LEDs: Red (635 nm), Green (525 nm), Blue (460 nm) |
Scanning side and insertion direction | Two-sided |
Scan modality | Black and White, greyscale, RGB, red colour, green colour, blue colour |
Max. scan speed | 600 dpi resolution = 73 mm/s RGB 200/300 dpi resolution = 286 mm/s Black and White, greyscale 200/300 dpi resolution = 400 mm/s |
Min. scan length | 70 mm |
Max. scan length | 1000 mm |
Max. scan width | 217.4 mm |
Image format | .bmp, .jpeg, .png, .raw, .tiff (without compression), .tiff (CCITT3 compression), .tiff (CCIT4 compression), .tiff (RLE compression), .tiff (LZW compression) |
Functions | Mechanical deskew Image crop and software deskew (only for .jpg images) |
Paper width | from 70 mm to 218 mm |
Paper weight | from 50 g/m2 to 200 g/m2 |
Power supply | from 12 Vdc to 24 Vdc ±10% (optional external power supply) |
Medium consumption | 1 A |
Operating temperature | from 0 °C to +50 °C |
Dimensions | 274 (L) x 77 (H) x 127.4 (W) mm, with cover closed 274 (L) x 144 (H) x 139.4 (W) mm, with cover open |
Weight | 1980 g |
